【產品介紹】
l 適配器外觀平滑、潔凈、無油污及毛刺，無傷痕和裂痕
Appearance of adapter must be smooth and clean. It has no oil, burrs, scars and crack；
l 適配器外觀顏色鮮明、一致性好
The color of adapter must be bright in good consistency；
l 各零部件組合須平整，插頭與適配器的插入和拔出須平順、輕松、卡子有力；
All parts of adapter can assembly well without difficulty, it should be easy and
comfortable to plug in and pull out connector from adapters, the clip should be
powerful.
l 模式：單模
Modes：SM ；
l 高精密陶瓷套管；
sleeve in high precision；
l 所有材料滿足 RoHS 要求；
all material meets RoHS
l 低插入損耗；low insertion loss
l 重復性好； good repeatability
l 互換性好；good interchangeability
l 安裝方便； Easy installation
l 溫度穩定性好；good temperature stability
l 光纖通信系統；Optical fiber communication system
l 有線電視網絡；cable television network
l 局域網,廣域網；LAN,WAN
l 光纖接入網；Optical fiber access network
l 視頻傳輸；video transmission
|
項目 Project |
指標 Values |
||
|
參照標準 Reference standard |
YD/T 1272.4-2007 |
||
|
插入損耗 Insertion loss |
≤0.2dB |
||
|
各種試驗后的插損變化量 IL change absolute value |
低溫 low temperature |
溫度：-25℃ 時間：96小時 Temperature: -25℃ Duration: 96 h |
≤0.2dB |
|
高 溫 high temperature |
溫度：70℃ 時間：96小時 Temperature: 70℃ Duration: 96 h Temperature change rate: 1℃/min |
≤0.2dB |
|
|
濕 熱 Hot and humid |
溫度：40℃ 溫度：90%~95% 時間：96小時 Temperature: 40℃ Humidity: 90%~95% Duration: 96h Temperature change rate: 1℃/min |
≤0.2dB |
|
|
溫度循環 Temperature cycle
|
溫度：-10℃ to + 60℃ 時間：96小時 循環次數：12 Temperature: -10℃ to + 60℃ Duration: 96h Cycle times:12 Temperature change rate: 1℃/min |
≤0.2dB |
|
|
重復性 repeatability |
重復插拔10次 Insertion pull times:10 |
≤0.2dB |
|
|
機械耐久性 Mechanism durability |
插拔次數：500次 Insertion times: 500 cycles |
≤0.2dB |
|
|
鎖緊機構抗拉強度 Tensile strength Of coupling mechanism |
50N/10 Minute |
≤0.2dB |
|
|
插拔力 pull-out force |
≤19.6.N |
|
材料阻燃性能 Flame resistance |
UL94-V0 |
|
工作溫度 work temperature |
-25℃～+70℃ |
|
儲存溫度 storage temperature |
-25℃～+70℃ |
|
部件名稱 parts Name |
數量 Qty |
材質 Requirement |
|
外殼 Body(housing) |
2 |
ABS |
|
防塵帽 Dust cap |
4 |
PVC |
|
套管 Sleeve |
2 |
Zirconia Ceramic |
