【Product introduction】
l Appearance of adapter must be smooth and clean. It has no oil, burrs, scars and
crack；
lThe color of adapter must be bright in good consistency；
l All parts of adapter can assembly well without difficulty, it should be easy and
comfortable to plug in and pull out connector from adapters, the clip should be
powerful.
l Modes：SM ；
l sleeve in high precision；
l all material meets RoHS
l low insertion loss
l good repeatability
l good interchangeability
l Easy installation
l good temperature stability
l Optical fiber communication system
l cable television network
l LAN,WAN
l Optical fiber access network
l video transmission
l test equipment
|
Project |
Values |
||
|
Reference standard |
YD/T 1272.1-2003 |
||
|
Insertion loss |
≤0.2dB |
||
|
IL change absolute value |
low temperature |
Temperature: -40℃ Duration: 168 h |
≤0.2dB |
|
high temperature |
Temperature: 85℃ Duration: 168 h Temperature change rate: 1℃/min |
≤0.2dB |
|
|
Hot and humid |
Temperature: 40℃ Humidity: 90%~95% Duration: 168h Temperature change rate: 1℃/min |
≤0.2dB |
|
|
Temperature cycle
|
Temperature: -40℃ to + 85℃ Duration: 168h Cycle times:21 Temperature change rate: 1℃/min |
≤0.2dB |
|
|
repeatability |
Insertion pull times:10 |
≤0.2dB |
|
|
Mechanism durability |
Insertion times: 500 cycles |
≤0.2dB |
|
|
Tensile strength Of coupling mechanism |
68.6N/10 Minute |
≤0.2dB |
|
|
pull-out force |
≤19.6.N |
|
Flame resistance |
UL94-V0 |
|
work temperature |
-25℃～+75℃ |
|
storage temperature |
-40℃～+85℃ |
|
parts Name |
Qty |
Requirement |
|
Body(housing) |
1 |
PC |
|
Dust cap |
2 |
PP |
|
Stainless steel shrapnel |
1 |
SUS304 |
